Controllers & Interfaces

Controllers & Interfaces

We have a variety of controllers and user interfaces to meet specific needs. Some features include:

  • Ethernet/IP
  • Historical Data logging
  • Event logging
  • Alarm relays and analog outputs

eSentry 4

The eSentry controller was designed to make the integration of sensor into your existing process control system easy. It can communicate with up to four (4) Atlas to Titan sensors via an RS485 network. The standard configuration provide relay outputs to allow a user to mornitor or visually inspect the communication status of each sensor and the associated dust alarms. Analog output can be provided as an option.

All data on an eSentry controller can be accessed by plant personnel using either Modbus TCP or Ethernet/IP. The current models are built on an existing PLC platform.

Sentinel 1

The Sentinel 1 communicates with one (1) Atlas or Titan sensor on an RS485 network. The Sentinel 1 was designed to simplify the data logging requirements of EPA's MACT Rules and provide a user interface with real-time dust trending. The user can configurate the sensor from the display screen to define:

  • Rolling average period
  • Alarm limits and delay time
  • QA Check auto frequency or time of day
  • Analog output scaling
The Sentinel 1 comes in two (2) versions. The STD model has a 4.3" screen and the XL has a 7" screen.

Sentinel 4

The Sentinel 4 has a 7" color touch screen and communicates with up to four (4) Atlas or Titan sensors on an RS485 network. The user can view live data display or real-time trends from each connected sensor. The Sentinel 4 logs historical data as well as an event log. All data logging meets the requirements of EPA's MACT Rules. The user can configurate each sensor from the display screen to define:

  • Rolling average period
  • Alarm limits and delay time
  • QA Check auto frequency or time of day
  • Analog output scaling
